The concrete shot blasting machine delivers professional solutions for concrete floor renovation and road maintenance. Manual grinding and traditional cleaning methods leave uneven textures and residual laitance. This advanced equipment adopts centrifugal blasting technology to accelerate steel shots and strip floor impurities. It solves common construction drawbacks efficiently. It delivers uniform roughness, clean surfaces, and reliable coating adhesion for all concrete projects.
Concrete Shot Blasting Machine Full Technical Parameters
Choosing suitable surface preparation equipment starts with clear parameter matching. YG Machinery offers three mainstream models for small workshops and large infrastructure sites. Each model features adjustable speed, stable power, and low material consumption for long-term construction.
| Parameter | YG-270 (Single) | YG550/600 (Double) | YG-850 (Double) |
|---|---|---|---|
| Shot Blasting Wheel Diameter | 200mm | 200mm | 200mm |
| Working Width | 270 mm | 550/600 mm | 800 mm |
| Walking Speed | 0.5~20 m/min | 0.5~33 m/min | 0.5~33 m/min |
| Concrete Cleaning Efficiency | ≥180 m²/h | ≥400 m²/h | ≥600 m²/h |
| Steel Plate Cleaning Efficiency | 15-25 m²/h | 75-100 m²/h | 100-160 m²/h |
| Dust Pipe Diameter | 120 mm | 150 mm | 150 mm |
| Steel Ball Diameter Suggestion | 1.2-1.5 mm | 1.5-1.8 mm | 1.5-1.8 mm |
| Steel Pill Consumption | 10 g/m² | 10 g/m² | 10 g/m² |
| Matching Dust Collector | Seven-core automatic backflush vacuum cleaner | Eight-core automatic backflush vacuum cleaner | Eight-core automatic backflush vacuum cleaner |
| Shot Wheel Motor Power | 11 kW | 11*2 kW | 15*2 kW |
| Shot Wheel Motor Current | ≤ 15 A | ≤ 22*2 A | ≤ 28*2 A |
| Walking Motor Power | 0.5 kW | 0.5 kW | 1.5 kW |
| Walking Motor Current | 1 A | 1 A | 3 A |
| Machine Dimension | 1000*300*1100 mm | 1950*720/775*1400 mm | 1950*1020*1550 mm |
| Net Weight | 150 kg | 570 kg | 700 kg |
| Power Requirement | 400V, 50Hz, 100A, CEE socket | ||
Get Factory Quote | WhatsApp/Tel: +86 183 3715 2861
Core Advantages of Concrete Shot Blasting Machine for Surface Treatment
- Adaptable Operation: Adjustable walking speed fits different concrete hardness and treatment requirements.
- Stable Coating Performance: Uniform shot impact forms consistent roughness for reliable paint adhesion.
- Cost-Saving Feature: Fixed low steel pill consumption greatly controls overall shot blasting concrete cost.
- Eco-Friendly Working: Matched dust collectors reduce pollution and keep sites clean.
- Wide Compatibility: It works well for both concrete floors and rusted steel plate pretreatment.
- High Project Efficiency: Less manual work and lower rework rates shorten construction cycles.
Common Application Scenarios for Concrete Shot Blaster for Sale
Professional surface preparation equipment covers multiple construction and renovation fields. It serves small indoor floor repairs and large outdoor infrastructure projects. Every application meets strict industry surface treatment standards.
- Industrial Warehouse Flooring: Remove old paint and laitance before epoxy floor coating construction.
- Municipal Road Renovation: Improve road anti-slip performance by uniform surface texturing.
- Bridge Deck Maintenance: Clean bridge surfaces before waterproof layer paving work.
- Steel Structure Treatment: Remove rust and oxide layers for factory steel plates.
- Airport Pavement Upgrading: Restore runway friction and ensure flight safety standards.
- Parking Lot Renovation: Create stable rough surfaces for durable floor coating adhesion.
Its portable and self-propelled design allows flexible movement on complex job sites. It avoids repeated equipment handling and saves construction preparation time.
Real Project Case: Commercial Floor Renovation in Southeast Asia
A local construction contractor in Southeast Asia focused on industrial floor renovation projects. The team previously relied on traditional floor grinders for surface preparation. Manual processing caused uneven floor texture and low daily output.
Unqualified coating adhesion often led to rework and extra costs. The contractor wanted stable equipment to cut shot blasting concrete costs and improve project quality. Finally, they purchased our YG-600 double-head concrete shot blasting machine for large-area construction.
After official operation, the machine achieved stable 400 m²/h concrete blasting efficiency. It completed warehouse floor profiling and old coating removal efficiently. The uniform rough surface perfectly supported subsequent epoxy floor construction.
This concrete shot blaster for sale greatly reduced manual dependence and rework rates. The project finished ahead of schedule with zero quality complaints. The customer now applies this surface preparation equipment for all large-scale floor renovation orders.
Frequently Asked Questions About Concrete Shot Blasting Machine Selection
Compact YG-270 models fit small workshops and indoor floor repair tasks. Medium and large models suit road and bridge engineering teams.
Yes. It delivers more uniform roughness with less dust and faster speed. It also lowers long-term shot blasting concrete cost for large areas.
It forms consistent anchor patterns suitable for epoxy, paint, and waterproof coating bonding. Results meet standard construction requirements.
All models maintain a stable consumption of 10g per square meter. It controls operational costs for long-term projects.
Double-head 550/850 models support long-hour continuous operation. They adapt to high-intensity outdoor construction environments.
The machine features a simple structure and easy cleaning. Regular shot and dust system checks ensure stable long-term performance.
Yes. The self-propelled design and intuitive controls support single-person independent operation.Small indoor projects choose 270mm models. Large road sites adopt 550- 800 mm wide machines.
Yes. It provides more uniform texture and lower long-term operating costs.
Dual-wheel models support stable continuous operation for large-scale engineering projects.
Fixed low steel pill consumption and low failure rates reduce long-term project expenditure.
Concrete Shot Blasting Machine Manufacturer
YG Machinery is a professional manufacturer of construction surface treatment machinery. All concrete shot blasting machines undergo strict factory testing and quality inspection. We provide complete pre-sales model selection and customized project solutions. Our full after-sales service includes free operation training, long-term spare parts supply, and remote technical support. We help global clients reduce equipment failure rates and stabilize project progress. If you need reliable surface preparation equipment for your upcoming projects, contact our team today. We will analyze your site conditions and provide an accurate, cost-effective quotation within 8 hours.
